|Name:||Stainless Steel Traffic Barrier Parking Barrier Auto Parking System Access Control||Material:||2mm Cold Rolled Steel Plate|
|Operation Time:||1.8s,3s,6s||Net Weight:||48KG|
|Protection Grade:||IP54||Keywords:||Automatic Barrier Gates|
|Color:||Orange As Standard||Remote Control:||80-120M|
electric barrier gate,
car park barrier gate
Stainless Steel Parking Traffic Barrier Gate / Automatic Car Park Barriers Access Control
WHAT IS IT ?
Barrier Gate, also known as the block device, was originally introduced from abroad, the English name Barrier Gate, is dedicated to the road on the restricted motor vehicle access channel management equipment, is widely used in highway toll stations, parking system management vehicle access, In the management of vehicle access. Electric barrier can be achieved through the wireless remote control landing gear alone, can also be through the parking management system (IC card management system) to implement automatic management of the state, admission card to take off the vehicle, the appearance of parking fees automatically after the release of vehicles.
WHY CHOOSE US ?
The Wonsun barrier gate series ,which manufactured by our company,adopt the latest automatic technology and intelligent desigh ahead in this field .Meanwhile our barrier gates series have the promethean design,such as humanization clutch device,balance device,which makes our barrier gates work more safely and conveniently.And we believe our barrier gate series can meet your high quality demand.
HOW TO USE ?
1. Please select the right type of the barrier gates according to the specifications of the place.Fix the barrier gate case board with expansion bolts.
2. Fix the boom to the boom tray with the boom press board, then cover the boom capuche with the screws. After that ,fix the cover of the boom to the splint and fasten them with four screws of 4*16, and slip the cover tap with the cover by two 3*10 screws.
3. Unlock the clutch device with the clutch key clockwise .Move the boom to the horizontal and vertical manually to make sure there is no obstruction.Then turn on the power .
MORE DETAILS ABOUT LENGTH AND SPEED YOU NEED ,
AND THE TYPE OF ARM YOU WANT ,WELCOME CONTACT.
Before you order ,something you need to know :
|Voltage||AC 220V/110V±10%, 50/60HZ|
|Operation time||0.6s, 1s, 1.8s, 3s,4s,6s. Customized|
|Boom type||staight boom ,90°folding boom ,180° folding boom ,two fence boom ,three fence boom|
Galvanized plate or Cold roll plate, 2.0mm thickness sheet
|Spring And Bearing||Heat Treatment: more durable, more than 5 million times through operation testing|
Remote Control Distance
|Usually 80-120 meters, if there is less obstacles, even 150 meters or more|
with seven layers carton case
By Sea: big order(more than 100 sets), Cheap, suggested
|machine core||First generation|
100% pure copper motor :more durable ,safety and stable when barrier gate is working .Inside with anti -frozen oil ,which can make barrier runs normally in low temperature.
Motor cooling fan : it will operate automatically,when barrier works in high temperature or motor works in heavy duty .
AC motor : its strong and powerful ,can easily lift up even with additional signage installed no the barrier arm,AC motor is maintenance free ,as there is no carbon in the AC motor ,built in intelligent fan cool the motor during heavy usage.
Photo electrical limit switch : photo electrical limit switch uses smart motor counter to auto detect open/close position for higher accuracy and better stability. No more mechanical wear and tear which causes the arm to tilts up or down.
Arm swing out : arm will swing out when hit directly by vehicle to avoid further damage on the vehicle .
Arm auto reverse : built in smart collision detection technology allows arm to auto reverse when hit with an obstacle during closing to prevent further scratches & dents on the vehicle .Optional photo beam allows arm to auto reverse earlier before hitting the vehicle . Optional photo beam allows arm to auto reverse earlier before hitting the vehicle.Optional rubber lining to protect the vehicle from further damages.
Clutch device : wonsun clutch device can be conveniently unlocked to manually open or close the arm without removing the whole top cover or body housing . Resulting in hassle free operation and all components inside the barrier body are safe from danger and vandals.
Sturdy housing : housing is made with 2.0 mm cold rolled steel sheet for extra durability to support longer arm. Housing body is coated with epoxy paint for waterproof protection
This automatic gate barrier provides a secure and convenient solution of stopping unauthorized vehicle of giving access :airport, shopping mall,warehouse,hotel, factories, condominium, car rental companies, Parking Lots, Toll Gates, Goods Yards, Railway Crossings,Highway, Hotel, Community,Bus Station,Commercial Premises, Aparment Block ,etc
We use strong carton case with air bubble filled inside to protect products and save your cost.
|description||Max boom length||Action time (s)||boom height ( m)|
|Slow speed ,straight||L ≤ 6 m||6||0.83|
|Medium speed ,straight||L ≤ 4.5 m||3||0.83|
|Quick speed,straight||L ≤ 3 m||1-2||0.83|
|Fastest speed ,straight||L ≤ 2.5 m||0.6-0.8||0.83|
|90° Folding boom||L ≤ 5 m||0.6-6||0.83|
|180° Folding boom||L ≤ 5 m||0.6-6||0.83|
|fence boom (2/3)||L ≤ 4.5 m||6||0.9/1.5|
