1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction

Name: 1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction
Brand: Shenzhen Wonsun Machinery & Electrical Technology Co. Ltd
SKU: DZ-912
Price: 399 USD
Availability: InStock

Product Details

Place of Origin: CHINA

Brand Name: WONSUN

Certification: CE ISO SGS

Model Number: DZ-912

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: $399/set

Packaging Details: Packed in bubble wrap firstly,and then reinforced with carton for outer packing

Payment Terms: L/C, T/T, Western Union

Supply Ability: 3000 set/sets per month

Get Best Price

Contact Now

Specifications

Description

Specifications

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                      Interchangeable Arm Direction Barrier Gate, traffic Barrier Gate OEM, DC Brushless Barrier Gate


Name:	1st Generation DC Brushless Barrier Gate	Model:	DZ-912
CEM/ODM:	Supported	Driving Method:	DC Brushless Motor
Humidity:	≤90%	Motor No-load Speed:	2000r/min

Name:	1st Generation DC Brushless Barrier Gate
Model:	DZ-912
CEM/ODM:	Supported
Driving Method:	DC Brushless Motor
Humidity:	≤90%
Motor No-load Speed:	2000r/min

Description

1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction

1st Generation DC Brushless Barrier Gate with Arm Direction Can Be Quickly Interchanged use in traffic barrier

Model No.	DZ-912
Framework Material	Cold-roll sheet
Beam	Aluminum alloy
Dimension	340289928mm
Net Weight	48KG
Input Interface	Photo cell, loop detector, parking system,wire control
Input	12V relay signal or Pulse Wide>100MS
Power Supply	DC24V/AC110V/220V,50/60HZ
Related Power	200W
Working Temperature	-35°C to +65°C
Remote control system	≤100m(open,sunny weather)
MCBF	5million time
Push Button	Support
Remote Control	Two button remote transmitter, Distance≤100m
Protection class	IP54
Beam Length	3~6Meters
Opening/Close Time	1.5sec-8sec

Functions and Features:

1 The running speed can be adjusted(1.5sec-8sec)

2 Arm direction can be quickly interchanged

3 Barrier gate up and down signal relay switch output

4 R&G traffic light relay switch signal output

5 External loop detector signal anti-smashing interface

6 Infrared sensor signal anti-smashing interface

7 Count mode interface

8 Arm swing out function,when the vehicle hit the barrier gate,the arm can be swing out to avoid further damage on the vehicle and barrier machinery core

9 High-sensity arm auto reverse function (intensity can be adjusted )

10 Parking system interface

11 RS485 coomunication interface

12 Power off the backup battery inerface

13 Automatic arm lift function when power off (need to add power storage module)

14 1st Generation DC Brushless Barrier Gate

15 Motor no-load speed(2000r/min)

1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction 0

1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction 5

1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction 6

1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction 8

1st Generation DC Brushless Barrier Gate with Interchangeable Arm Direction 10

Our Services

Service for free:
1. One year free service is supplied(not including the arm and remote)

2. Lifetime charged service is supplied

3. Technical service is supplied

4. OEM: we can customized machine case, color, logo for you, which accroding to your detailed requirements.

5. Technical support and aftersales service, it is a long term relatioship between us.

6. Price can be negotiable when you have big order quantity.

Service for charging:

1. Broken by wrong installation

2. Broken by improper voltage

3. The surfaces of the barrier destroyed by wrong installation and usage

4. Overdue service items are out of our promise.

FAQ

Q: Are you trading company or manufacturer ?
A: We are a professional barrier gate manufacturer, indusrty and trade integration.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.

We can send it for you by DHL/Fedex/TNT/SEA/AIR or your requirments.
Q: How about payment terms our company provide?
A: T/T or Western Union or
Q: Do you provide samples ?
A:No,we don't provide free samples. The MOQ of our products is 1pc.
