Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate

Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate
Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate

Large Image :  Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate

Product Details:
Place of Origin: China
Brand Name: WONSUN
Certification: CE
Model Number: DZ-132
Payment & Shipping Terms:
Minimum Order Quantity: 1PC
Price: Negotiable
Packaging Details: Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Delivery Time: 3-7 working days after received your payment
Payment Terms: T/T,Western Union,Money Gram,Alibaba Trade Assurance,Paypal etc.,
Supply Ability: 1000 Sets/Month

Speed Adjustable IP44 1850rpm 8s Boom Barrier Gate

Description
Running Speed: 1.5s-8s Rated Voltage: DC24V
Advantages: Speed Adjustable, Bi-direction LEFT Or RIGHT, Hall Limit Certificate:: WONSUN
Brand Name:: -35℃~+85℃ Product Name: Factory Price Speed Adjustable Boom Barrier Brushless DC 24V Motor Traffic Barrier Gate With 12V Backup Battery
High Light:

1850rpm Boom Barrier Gate

,

8s Boom Barrier Gate

,

IP44 Automatic Car Park Barrier

Factory Price Speed Adjustable Boom Barrier Brushless DC 24V Motor Traffic Barrier Gate With 12V Backup Battery


China 5 Star supplier of barrier gate. If any interest, please contact me freely.
Email: keira@wonsunbarrier.com
Skype: zimin1314
Whatsapp: +86 185 0748 1610
Wechat: Keira_Xia


Features


The running speed can be adjusted from 1.5s to 8s
Can be quickly interchanged
Open the barrier gate by motor wheel when power off ,automatically reset after power on
Curved crank arm three- link movement structure, the operation is stable
Wireless remote control control open/close
Auto reverse function(force adjustable)
Infrared photocells connector is available
Loop detector connector is available.
Well-integrated with car parking system equipment,with wire control(must be switch signal)
Connector for traffic light(AC220V,power less than 40W)
Offering dry contact signal for car parking system(COM,NC,NO)
Auto-delay when closing(adjustable)
RS485 or CAN network communication interface(no need to install module)
Counting interface
24V backup battery interface(Can be charged by using solar energy)



Technical parameters


1 Working temperature(motor): -35℃~+85℃
2 Rated voltage:DC24V
3 Running speed:1.5s-8s
4 Rated current:8.58A
5 Rated power:140W
6 No-load speed:1850rpm
7 Rated speed:1400rpm
8 Output Power:56.8N.m
9 Relative humidity:≤90%
10 Remote control distance:≤100M(in the open place)
11 IP Degree:IP44
12 Max length of arm:6M



Electrical installation, wiring diagram

1 All the electrical connections are done before delivery and please do not change it randomly.The necessity
is to connect the AC220V power and grounding connection.
2 Traffic light connector:it can connect power no more than 40W.
3 Infrared photocells an-hit connector: connect the switch signal for receiver output.
4 Loop detector connectors:it supports both externally and internally loop detector(only one way can be chosen).
If external type is selected,just connect the switch signal for loop detector output.
If the internal type is selected,need connect the wire signal to vehicle detector wire interface.
5 Car parking system connectors: connect the system switch signal to this connector,then it can control the barrier gate operation.
6 Limit switch signal of up/down:with output COM,NO,NC,it monitoring the status of the barrier gate.
7 RS485 connector:after chosen the options RS485 module,it can manage MAX 15 pieces of barrier gates by PC software.



Product Maintenance

1 Keep the barrier gate clean
2 Check the joints ever month in case of any loose parts.
3 Check the spring elasticity after the barrier gate running 3000 times.
4 Check the easily worn-out parts(like the spring,limit switch),every half year and renew it.
5 Remote control distance will be shortened or not work in case like big object screening,battery exhausting,extreme weathers.


Packing List


NameSpecificationQtyUnitNote
Hexagon screwM12*702PieceFixing the boom
Boom press board 1piece
Mounting batten 2pieceFixing the case
Expansion boltM16*1504unitFixing the case
Case Key 2unit
Remote controller 2unit
Instruction 1piece





FAQ



1-Can you install using loop detector or pressure sensor on it?

Yes,the stanadard advertising barrier gate have loop detector and pressure sensor.



2-How about the guarantee and after sale service?

We have 1 year quality guarantee, We own well tranied and passional sales & aftersale services who can speak fluent English language.



3-How long is the leading time?

For standard item

10-50 sets:5 working days
50-100 sets:7-10 working days
200-500 sets:10-15 working days
For special item, or need custom design package or logo, need 3-10 working days longer.



4-How about the payment terms?

TT,western union,our company already joined the trade assurance,it will highly protect your order security.



5-How do you send the products to me,how long?

As our products are big volume,and heavy duty, we suggest you to ship by sea. You can also choose your own shipping

forwarder. it normally takes 7-60 days depend on different countries.



6-What is the package of the barrier gate?

Inside with a carton package.Then outside,there are wooden crate package.
