Product Details
Place of Origin: China
Brand Name: WONSUN
Certification: CE, ISO, SGS
Model Number: DZ-134
Payment & Shipping Terms
Minimum Order Quantity: 1PC
Price: USD200~250 per unit
Packaging Details: Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Delivery Time: 3-7 working days after received your payment
Payment Terms: T/T,Western Union,Money Gram,Alibaba Trade Assurance,Paypal etc.,
Supply Ability: 1000 Sets/Month
Name: |
2mm Thickness Galvanized Steel Vehicle Barrier Gate With LED Screen |
Color: |
Black,red,blue,white |
Voltage: |
220V±10%, 110V±10%, 50/60HZ |
Rated Power: |
80W |
Capacitor: |
9+9uF/450W |
Telescopic Arm: |
Optional |
Name: |
2mm Thickness Galvanized Steel Vehicle Barrier Gate With LED Screen |
Color: |
Black,red,blue,white |
Voltage: |
220V±10%, 110V±10%, 50/60HZ |
Rated Power: |
80W |
Capacitor: |
9+9uF/450W |
Telescopic Arm: |
Optional |
2mm Thickness Galvanized Steel Vehicle Barrier Gate With LED screen
Product Introduction
Barrier Gate with LED screen is a luxury model, specially designed to meet users with high requirements. The LED screen is in the middle of the barrier housing. With a specified software and data wire, you can input the detailed time information like, 20:00, Friday, June 30th 2013. And you can input any words you like, in English and Chinese. This barrier gate also has traffic light indication. Green and Red light remind people whether it can be transited or forbidden to transit.
| Model | WSTP-134 |
| Working Temperature | -40℃～+75℃ |
| Voltage | 220V±10%, 110V±10%, 50/60HZ |
| Rated power | 80W |
| Relative humidity | ≤90% |
| Remote control distance | ≥30m |
| Gross weight | 64kgs |
| Speed | 1S. 3S, 6S |
| Max boom length | 8 meters |
Advantages
Barrier Gate with LED screen uses the first generation motor. It is stable and has long service life performance, running more than five million times. Its housing is made of galvanized steel with 2mm thickness, and painted, so that the barrier can be used in door and outdoor.
The barrier core is special and main parts are aluminum alloy casting. The barrier gate will automatically reverse when the boom meets the obstruction. The barrier works well with infrared photocells, loop detectors, the boom will automatically rise up when it meets pedestrian and vehicles. The clutch of the barrier gate is fixed inside the housing, which can be easily rotate manually with any clutch key; Meanwhile, the exclusive balance device makes the barrier gate work more safely and conveniently.
Functions
1. Manual release device to operate the barrier when power failure
2. Barrier motor with die-casting aluminum alloy is high-hermetic and easy for heat dissipation
3. Motor cooling fan to avoid the over-heating possibility
4. Automatic reversing when the barrier boom meets the obstruction
5. Auto closing realization through menu setting on the control panel
6. The barrier works well with infrared photocells, loop detectors, card readers, ticket dispensers, manual switch (wire control), and traffic light
7. RS485 Communication Module is compatible
8. Traffic light interface
9. LED Screen
10. Automatic moisture control
11. Infrared Photocells (optional)
12. Support the external and internal Vehicle Loop Detector (optional)
What we offer?
1.One-stop procurement service is available.
2.Quickest delivery and best aftersales service.
3.Veteran technician solves all your problems.
4.Passionate and professional sales makes a wonderful team.
5.Competitive and reasonable price with high quality products and advanced technology.
6.Providing the most professional solution as soon as possible according to your requirements.
