Inductive Vehicle Loop Detector for Car Parking Management System

China Inductive Vehicle Loop Detector for Car Parking Management System supplier

Large Image :  Inductive Vehicle Loop Detector for Car Parking Management System

Product Details:

Place of Origin: China
Brand Name: WONSUN
Certification: CE
Model Number: WSTV-410

Payment & Shipping Terms:

Minimum Order Quantity: 1PC
Price: Negotiate
Packaging Details: Packed in bubble wrap firstly, and then reinforced with carton for outer packing.
Delivery Time: 3-7 working days after received your payment
Payment Terms: T/T,Western Union,Money Gram,Alibaba Trade Assurance,Paypal etc.,
Supply Ability: 1000 Sets/Month
Contact Now
Detailed Product Description
Supply Voltage: 220V AC , 115V AC,24VDC/AC,12V DC/AC Storage Temperature: -40°C To +85°C
Output Relays: 240V/5A Voltage Tolerance DC: ±15%
Size Of Housing: 78x36x85 Mm Reaction Time:: 100ms

Inductive Vehicle Loop Detector for Car Parking Management System



Quick Detail:



The WSTV-410 is a single channel inductive loop detector designed for parking and access control applications.



The detector is connected to an inductive loop mounted in the road surface. When vehicles pass over the loop the detector switches on an output.



The use of microprocessor and surface mount technology enables a large number of functions to be incorporated into a small package.



The WSTV-410 is compatible with most single channel detectors on the market and is easy to set-up and install.




Specification:



Supply voltage AC 220V, 110V, 24V, 12V
Supply voltage DC  24V, 12V
Sensitivity  adjustable in 3 increments (high .medium. low)
Operating temperature  -20°C to +65°C
 Storage temperature -40°C to +85°C
Frequency range  20 kHz to 170 kHz
Reaction time  100ms
Loop inductance Ideal:80μH to 300μH
(incl. conn. wiring)   max:50μH to500μH
Loop connection  <5m optimal
Loop connection wiring  Maximum length 200 meters
  Twisted at least 20 times per meter
Dimensions  36 x74x85 mm





Application



Loop detectors are used wherever vehicles have to be detected. Like monitoring and safe guarding access ways to counting vehicles. The output signal can be used for controlling door and gate drive mechanisms, operating barriers, controlling traffic light systems in car parks or activating card dispensers in car parks.



The WSTV-410 is a single channel inductive loop detectors. The principle is based on a change in the inductance within the loop which is caused by the metallic components of passing vehicles. The changes are picked up and evaluated by a microprocessor. Ease of use thanks to automatic calibration when the operating voltage is applied.




Features:



Single channel inductive loop detectors

Principle is based on change in inductance within loop which is caused by metallic components of passing vehicles

Changes are picked up and evaluated by a microprocessor, easy to use due to automatic calibration when operating voltage is applied

Used wherever vehicles have to be detected, like monitoring and safe guarding access ways for counting vehicles

Output signal can be used for controlling door and gate drive mechanisms, road barriers, controlling traffic light systems in car parks or activating card dispensers in car parks
