Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application

China Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application supplier
Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application supplier Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application supplier Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application supplier

Large Image :  Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application

Product Details:

Place of Origin: China
Brand Name: WONSUN
Certification: CE
Model Number: DZ-132

Payment & Shipping Terms:

Minimum Order Quantity: 1
Price: negotiate
Packaging Details: carton box
Payment Terms: T/T, Western Union
Supply Ability: 2000/month
Contact Now
Detailed Product Description
Distance Of Remote Control: 100M>L≥30M In The Open Place Speed: 1s, 2s, 4s
Color: Black&Red, Blue&White, Grey&white Rated Power: 80W,capacitor:9+uF/450W
Voltage: 220V±10%,50HZ Or 110V±10%,60HZ Product Name: Interchange Arm Diraction Parking Barrier Gate For Car Parking Lot System

Interchange Arm Diraction Parking Barrier Gate For Car Parking Lot System





1. Product Series and Parameter



Boom type Boom Length (L) Operation time(S) Height between boom and ground(M)
Straight boom 6M ≥L>5M 6S H=0.83M
5M≥L≥4.5M 6S
4.5M>L≥3M 6S
90 degree folding boom L≤5M 6S
180 degree folding boom L≤5M 6S
Two fe nce boom 5M≥L≥4M 6S H=0.9M
4M>L≥3M 6S
Three fence boom 5M≥L≥4M 6S H=1.5M
4M>L≥3M 6S





2. Functions and Features



2.1.The arm direction can be quickly interchanged

2.2.Open the barrier gate by motor wheel when power off and automatic locking when power on.

2.3.Balance boom running with a motor transmission of cranks and shafts.

2.4.Remote control to operate the barrier gate.

2.5.Auto-reverse when the boom meets obstruction.

2.6.Infrared photocells connector is available.

2.7.Loop detector connector is available.

2.8.Well-intergrated with car parking system equipment,with wire control(must be switch signal).

2.9.Connector for traffic light(AC220V,power less than 40W)

2.10.Offering dry contact signal for car parking system(COM,NC,NO)

2.11.Auto-delay when closing(adjustable)





3. Technical Data



3.1 Working temperature(motor): -35℃~+85℃

3.2 Working temperature(control panel): -35℃~+85℃

3.3 Voltage:220V±10%,50HZ or 110V±10%,60HZ

3.4 Rated Power:80W,capacitor:9+uF/450W

3.5 Humidity:≤90%RH

3.6 Distance of remote control:100M>L≥30M in the open place





4. Boom position adjustment



4.1 First please set the arm horizontally and vertically through regulation nut to lengthen or shorten the connecting rod.And then tighten M12 safety nuts.

4.2 To make the arm well balance,please adjust the M8*140MM spring redulating screw accordingly.

4.3 For the barrier gate with double springs,please adjust the two springs simultaneously.


Interchange Arm Diraction Parking Barrier Gate Car Parking Lot System Application




FAQ:

Q: Are you trading company or manufacturer ?
A: We are a professional barrier gate manufacturer.
Q: How long is your delivery time?
A: Generally it is 2-5 days if the goods are in stock. or it is 5-7 days if the goods are not in stock, it is according to quantity.

We can send it for you by DHL/Fedex/TNT/SEA/AIR or your requirments.
Q: How about payment terms our company provide?
A: T/T or Western Union.
Q: Do you provide samples ?
A:No,we don't provide samples. The MOQ of our products is 1pc.
